T50 Gas Relief Valve Pressure range 6,90 - 36,24 bar, SS 316
GUARD™ T50 Gas Relief Valve Pressure range 6,90 - 36,24 bar, SS 316
GUARD™ T50 Gas Relief Valve Pressure range 6,90 - 36,24 bar, SS 316
GUARD™ T50 Gas Relief Valve Pressure range 6,90 - 36,24 bar, SS 316
GUARD™ T50 Gas Relief Valve Pressure range 6,90 - 36,24 bar, SS 316
GUARD™ T50 Gas Relief Valve Pressure range 6,90 - 36,24 bar, SS 316
GUARD™ T50 Gas Relief Valve Pressure range 6,90 - 36,24 bar, SS 316
GUARD™ T50 Gas Relief Valve Pressure range 6,90 - 36,24 bar, SS 316
GUARD™ T50 Gas Relief Valve Pressure range 6,90 - 36,24 bar, SS 316
GUARD™ T50 Gas Relief Valve Pressure range 6,90 - 36,24 bar, SS 316
GUARD™

T50 Gas Relief Valve Pressure range 6,90 - 36,24 bar, SS 316

€2.663,74
€2.201,44 Ex. BTW/VAT
T50 Gas Relief Valve Pressure range of 100525.5PSI(6.90 36.24Bar).
Design temperature -55 ~ 80 Degree Celsius.
Contact parts in 316 stainless steel with RTFE seal.

Part No. AF8034480001
Out of Stock
Article code: AF8034480001
Add to cart
Question/quotationDelivery times
Product description

T50 Gas Relief Valve Pressure range of 100525.5PSI(6.90 36.24Bar).
Design temperature -55 ~ 80 Degree Celsius.
Contact parts in 316 stainless steel with RTFE seal.

Part No. AF8034480001
Norminal Diameter DN80
Design Pressure PN63
Design Temperature -55 ~ 80 Degree Celsius
Material SS 316 with RTFE seal

Nominal Diameter DN80
