Foot Valves

Bottom discharge valves for tank containers & tank trucks (Foot Valves)

Bottom discharge valves, also known as foot valves or foot valves, are essential components for tank containers and tank trucks. They are directly mounted at the tank outlet and form the first safety barrier during the loading and unloading of liquids and chemicals.

At Guard Europe BV we supply high-quality bottom discharge valves designed for maximum safety, control, and chemical resistance. Suitable for ADR transport, industrial applications, and tank container systems.

Our foot valves operate in combination with a secondary shut-off device such as a butterfly valve or ball valve, creating a reliable double shut-off system.

Available versions:
DN80 (3 inch) and DN100 (4 inch), with outlet positions 30°, 45°, 90° and 180°. Available in manual or pneumatic operation.

For aggressive media, we offer coated and lined foot valves with increased chemical resistance and longer service life.

Applications:
Tank containers, tank trucks, bottom discharge systems, chemical and ADR transport.

All products comply with industrial standards and can be supplied with EN 14432 certification where applicable.

Please contact us for technical advice or a quotation tailored to your needs.

Filters

€
€

Tankcontainer Bottom Discharge Quick Flow Foot Valve 3" 45 degree

SKU: JX468001-00
€0,00 - €0,00
€0,00
€865,11
€1.046,78 - €1.046,78
€865,11
Excl. VAT/BTW
5+ in stock

3" 45 degrees Squick flow Footvalve Inlet flange drilled 814mm holes equi-spaced on a PCD 178mm, Outlet flange drilled 4x18mm holes equi-space...

View full details
€0,00 - €0,00
€0,00
€865,11
€1.046,78 - €1.046,78
€865,11

3" 45° Foot Valve

SKU: JS468009-00
€0,00 - €0,00
€0,00
€503,11
€608,76 - €608,76
€503,11
Excl. VAT/BTW
5+ in stock

3" 45º Foot Valve - Flange drilled 8x14 PCD 178. Outlet 4x18 PCD160 Option-Shutting-off device for emergency and fusible link.

€0,00 - €0,00
€0,00
€503,11
€608,76 - €608,76
€503,11
3 30 Foot valve with Heating 3
3 30 Foot valve with Heating Upon request

3" 45 Foot Valve with heating

SKU: JS468003-00
€0,00 - €0,00
€0,00
€945,44
€1.143,98 - €1.143,98
€945,44
Excl. VAT/BTW
Upon request

3" 45 degrees Foot valve with Heating. Heating for the transport of fluids that require it. Option : Shutting-off device for emergency and fusible ...

View full details
€0,00 - €0,00
€0,00
€945,44
€1.143,98 - €1.143,98
€945,44
Upon request

3” 45° Foot Valve, PFA lined

SKU: JX468012-00
€3.503,74 - €3.503,74
€2.895,65
€3.503,74 - €3.503,74
€2.895,65
Excl. VAT/BTW
Only 1 Left!

WAMP: 4 Bar  Temperature range: -40 to 190 C

€3.503,74 - €3.503,74
€2.895,65
€3.503,74 - €3.503,74
€2.895,65

3″ 45 ° Halar coating Footvalve

SKU: JS468025-00
€0,00 - €0,00
€0,00
€1.257,12
€1.521,12 - €1.521,12
€1.257,12
Excl. VAT/BTW
Only 1 Left!

3″45° Halar coated Footvalve – Inlet flange drilled 8x ф 14mm holes equi-spaced on a PCD ф 178. Outlet flange drilled 8x ф 16.5mm holes equi-spaced...

View full details
€0,00 - €0,00
€0,00
€1.257,12
€1.521,12 - €1.521,12
€1.257,12
3 30 Footvalve 2
3 30 Footvalve

3" 30° Foot Valve, Inlet 8×φ14×PCD178, 4×φ 18×PCD178

SKU: JS368002-00
€0,00 - €0,00
€0,00
€469,39
€567,96 - €567,96
€469,39
Excl. VAT/BTW
Only 5 Left!

3" 30 degrees Foot Valve Inlet flange drilled 4x18mm and 8x 14mm holes equi-spaced on a PCD 178mm, Outlet flange drilled 4x 18mm holes equi-spaced ...

View full details
€0,00 - €0,00
€0,00
€469,39
€567,96 - €567,96
€469,39
3 30 Foot valve with Heating 2
3 30 Foot valve with Heating
Upon request

3" 30° Foot Valve with heating, Inlet 8×φ14× PCD178

SKU: JS368003-00
€0,00 - €0,00
€0,00
€925,44
€1.119,78 - €1.119,78
€925,44
Excl. VAT/BTW
Upon request

3" 30º Bottom valve with heating - Heating for the transport of liquids that require it. Option: shut-off device for emergencies and melt safety.

€0,00 - €0,00
€0,00
€925,44
€1.119,78 - €1.119,78
€925,44
Upon request
3 180 Footvalve 2
3 180 Footvalve
Upon request

3" 180 degrees Foot Valve

SKU: JS168001-00
€0,00 - €0,00
€0,00
€573,69
€694,16 - €694,16
€573,69
Excl. VAT/BTW
Upon request

3" 180-degree bottom valve - Inlet flange drilled with 8x14mm holes equidistant from a PCD of 178mm, Outlet flange drilled with 4x14mm holes equidi...

View full details
€0,00 - €0,00
€0,00
€573,69
€694,16 - €694,16
€573,69
Upon request

4" 45° Manual Bottom Discharge-Steam heated - Pointed Poppet

SKU: JX464C04-00
€2.354,66 - €2.354,66
€1.946,00
€2.354,66 - €2.354,66
€1.946,00
Excl. VAT/BTW
5+ in stock

Quick flow- SS316 — Flange drilled 8× Φ 18× PCD 210.Outlet 8x φ18x PCD180

€2.354,66 - €2.354,66
€1.946,00
€2.354,66 - €2.354,66
€1.946,00

4" 45 degrees Foot Valve in SS 316 FEP / Silicon Seal

SKU: JS464C01-00
€0,00 - €0,00
€0,00
€870,12
€1.052,85 - €1.052,85
€870,12
Excl. VAT/BTW
Only 1 Left!

4" 45º Bottom Valve - Inlet flange drilled with 8x18 holes equally spaced on a 210 mm PCD; Outlet flange drilled with 8x18 holes equally spaced on ...

View full details
€0,00 - €0,00
€0,00
€870,12
€1.052,85 - €1.052,85
€870,12
Upon request

4″ 45° Swing Footvalve

SKU: JX464C01-00
€0,00 - €0,00
€0,00
€1.618,09
€1.957,89 - €1.957,89
€1.618,09
Excl. VAT/BTW
Upon request

4" 45 Quick Flow Bottom Valve - Inlet flange drilled 8 18mm holes equi-spaced on a PCD 210, Outlet flange drilled 818mm holes equi-spaced on a PCD ...

View full details
€0,00 - €0,00
€0,00
€1.618,09
€1.957,89 - €1.957,89
€1.618,09
Upon request
4%22 Bottom discharge
4%22 90 degree bottom discharge
Upon request

4" 90 Degree Quickflow Bottom Discharge, Manually Operated

SKU: JX964C01-00
€0,00 - €0,00
€0,00
€1.593,00
€1.927,53 - €1.927,53
€1.593,00
Excl. VAT/BTW
Upon request

316   JX964C01-00

€0,00 - €0,00
€0,00
€1.593,00
€1.927,53 - €1.927,53
€1.593,00
Upon request
5%22 180 Foot Valve 2
5%22 180 Foot Valve
Upon request

5" 180 degrees Foot Valve in SS316

SKU: JS165C01-00
€0,00 - €0,00
€0,00
€824,96
€998,20 - €998,20
€824,96
Excl. VAT/BTW
Upon request

5" 180º foot Valve - inlet flange drilled with 8x18 holes equally spaced on a 210 mm PCD; outlet flange drilled with 8x18 holes equally spaced on a...

View full details
€0,00 - €0,00
€0,00
€824,96
€998,20 - €998,20
€824,96
Upon request
5%22 30 Foot Valve 2
5%22 30 Foot Valve
Upon request

5" 30 degrees Foot Valve SS 316

SKU: JS365C01-00
€0,00 - €0,00
€0,00
€824,96
€998,20 - €998,20
€824,96
Excl. VAT/BTW
Upon request

5" 30º Foot Valve - inlet flange drilled 8x18 holes equi-spaced on a 210mm PCD; outlet flange drilled 8 18 holes equi-spaced on a 200mm PCD. Contac...

View full details
€0,00 - €0,00
€0,00
€824,96
€998,20 - €998,20
€824,96
Upon request
